Managing Thermals: Breaking Through Power-density Barriers

The number of semiconductors in nearly every application is multiplying, and many design challenges facing electronics engineers tie back to the need for greater power density.

A few application examples come to mind:

• Hyperscale data centers: Rack servers are using an incredible amount of power, challenging utility companies and power engineers to keep up with increasing demands.
• Electric vehicles:  The transition from internal combustion engines to 800 V battery packs comes with an exponential increase in semiconductor content for the powertrain.
• Commercial and home security applications:  As video doorbells and Internet Protocol cameras become more prevalent, their shrinking sizes constrain the necessary thermal solution.

What stands in the way of achieving higher power density?

Thermal performance is an electrical byproduct of power-management integrated circuits (ICs), which you can’t ignore or “optimize out” with filtering components at the system level. The mitigation of thermals requires critical micro-adjustments throughout every step in the development process so that the design can achieve its system requirements for a given size constraint. Following are three key areas TI focuses on to optimize thermal performance and breakthrough power-density barriers at the chip level.



Process Technology Innovations

Many global semiconductor manufacturers are racing to offer power-management products that leverage process technology nodes to achieve higher performance capabilities in industry-standard packages. For example, TI continues investing in 45- and 65-nm process technologies that leverage its internal technology development, along with 300-mm manufacturing efficiencies, to offer products optimized for cost, performance, power, precision, and voltage levels. Process technology advancements help create products that maintain high performance under various thermal conditions. For instance, reducing the specific on-state resistance (RSP) or drain-to-source on-state resistance (RDS(on)) of integrated metal-oxide-semiconductor field-effect transistors (MOSFETs) minimizes die size while enhancing thermal performance. The same is true for other semiconductor switches such as gallium nitride (GaN) or silicon carbide.



Figure 1. The TPS566242 synchronous buck converter delivers up to 6 A of continuous current. Image used courtesy of Bodo’s Power Systems [PDF]



Take the TPS566242 buck converter, shown in Figure 1. New process nodes optimize the pin layout by integrating features and providing an extra ground connection that helps deliver 6 A of output current from a 1.6-mm-by-1.6-mm small outline transistor (SOT)-563 package. If you had asked me five years ago if tiny, simple leaded packages would be capable of that type of performance, I’d have been skeptical. But that’s the beauty of process technology!



Figure 2. The TLVM13660 includes four thermal pads on the bottom and has all signal and power pins accessible from the perimeter for easier layout and handling. Image used courtesy of Bodo’s Power Systems [PDF]



Circuit-design Techniques

In addition to more efficiency at the process technology level, creative circuit design also plays an important role in improving power density. Designers have historically used discrete hot-swap controllers to protect high-current enterprise applications. As a protection function, they are reliable, but with end-equipment manufacturers (and consumers) requiring more current capability, discrete power designs can grow far too large, especially for applications such as server power-supply units (PSUs) that often require 300 A of current or more.



Figure 3. 3-kW phase-shifted full bridge with the active clamp reference design. Image used courtesy of Bodo’s Power Systems [PDF]



The  TPS25985  eFuse pairs an integrated 0.59-mΩ FET with a current-sense amplifier. This amplifier, plus a new active current-sharing approach, provides an easy way to allow for temperature monitoring. By pairing efficient switches with creative integration approaches, the TPS25985 can deliver up to 80 A of peak current, and you can easily stack multiple eFuses for a higher power.



Thermally Optimized Packaging Research and Development

Although reducing the amount of heat dissipated into the printed circuit board (PCB) or system is a basic requirement, the reality is that undesirable heat still lingers, especially as the power requirements or your system’s ambient temperature increase. TI has recently enhanced the performance of its HotRod quad-flat-no lead (QFN) packages, including larger die-attach pads (DAPs) to facilitate greater heat dissipation. Figure 2 shows the total DAP area and pin accessibility of the 6 A, 36 V  TLVM13660 step-down power module.

To learn more about the evolution of these packages, see Designing with small DC/DC converters: HotRod QFN vs. Enhanced HotRod QFN packaging.



System-level Thermal Solutions

For high-power applications like server PSUs, GaN with top-side cooling is a highly effective way to remove heat from the IC without heating up the PCB. The  LMG3522R030- Q1  GaN FET integrates a gate driver and protection features in a top-side cooled package. Figure 3 illustrates the isolated DC/DC section of the  3 kW phase-shifted full-bridge with active clamp reference design with > 270-W/in3 power density, which leverages the LMG3522 and achieves a peak efficiency of 97.74%.

Maintaining performance while reducing the impact of thermals can only happen with a multi-faceted approach to process and packaging technology and power design expertise. At TI, it’s a challenge that product designers, systems engineers, packaging research and development, and manufacturing teams are all hyper-focused on–achieving greater power density without thermal pitfalls.



Additional Resources

• Find devices and technical resources to solve your density challenges
• Watch the training series, Understanding the Fundamental Technologies of Power Density
• Create a custom power-supply circuit with WEBENCH Power Designer



This article originally appeared in Bodo’s Power Systems [PDF] magazine.
