45W/65W Plastic Housing Constant Current LED Driver with PFC

Soon after two flicker free design indoor LED drivers, the IDLC family (plastic housing type) and the IDPC family (PCB board type) were released to the market, Mean Well has enlarged their product line of flicker-free LED drivers and has unveiled the new ODLC-45(45W)/65(65W) series.

This product is electrically a co-design effort including the IDLC and IDPC families, all these LED drivers offer constant current output mode and are equipped with built-in active PFC function. In addition all three families offer the same electrical specifications for models with identical output wattage, operate with the up to 86% working efficiency and comply with UL8750, ENEC EN61347-1,-2-13 and GB19510.1, .14 international safety regulations of LED lighting.

The standard product has a built-in 2-in-1 dimming function (0- to 10-Vdc or pwm signal) and models with12V/50mA auxiliary output are also offered giving LED luminaire system designers higher flexibility while planning the layout. This product is very suitable to be applied to the indoor LED luminaires requiring flicker free and low power consumption, such as LED panel lighting and LED flood lighting.

Other specifications include: ac input 90- to 295-Vac for the 45W units and 180- to 295-Vac for the 65W units; no-load power consumption as low as 0.5W; working temperature range of -20 to +85 degrees C (case); short-circuit protection; and dimensions of 111 x 77 x 28.5 mm, for the 5W units and 121 x 77 x 28.5 mm for the 6W units.
