Power Sources Unlimited has added the Tracopower TCL Series of DIN rail mount ac-dc and dc-dc converters to its line up. Suitable applications for these economic DIN-rail power supplies are factory automation, light industrial, process control, instrumentation, office and residential needs where space is critical.
The TCL Series features an 85-264Vac input with total output power ratings of 24, 60 and 120 Watts. Output voltages of 5.1, 12, 24 and 48Vdc are standard and can be adjusted by the end user. A new TCL-DC product has also been introduced that provides a dc input voltage ranging from 18-75Vdc.
Standard features are tightly regulated outputs, high efficiency, power good signals, parallel and redundant operation and an operating temperature of -10 to +70 ° C.
The TCL Series boasts a compact footprint of 3.94" x 1.06" x 2.95" for the 24W unit.
Units are lightweight and ease of installation is accommodated by snap on mounting with the choice of either screw terminals or spring clamp connections. A mounting bracket is included with each unit, making chassis or wall mounting an easy option. The TCL Series supplies are approved to EN60950 for ITE and UL508 for industrial applications. The TCL60 modules also are compliant to the NEC Class 2 rating.
EN61000-3-2, -3 Class B EMI and EN61000-6-2 EMC Immunity are specified for the entire series. Pricing starts at $38.85 for 100 piece quantities.
