Five Techniques for Fast, Accurate Power Integrity Measurements

eGuide Overview

This eGuide offers practical tips for fast, accurate power integrity measurements, essential for modern electronics with lower power rail voltages and tighter tolerances. It covers five key techniques: optimizing viewing, reducing noise, ensuring sufficient offset, assessing switching and EMI, and accelerating measurements. The guide highlights the use of low-noise oscilloscopes, 1:1 probes with built-in offset, and proper settings such as vertical scaling and bandwidth limits. It also recommends frequency-domain analysis and fast update rates for more reliable results. Paired with the R&S®RT-ZPR20 power rail probe, R&S®RTO and R&S®RTE oscilloscopes deliver superior power integrity testing.
